220gsm 3K Plain Weave Carbon Fibre

220GSM / PW / FT300B 3K 40B / 1000mm or 1250mm

Hypetex 220gsm is a combination of 200gsm plain weave carbon fibre substrate and Hypetex colouring technology that looks symmetrical with a small checkerboard style appearance. In this weave the tows are woven in an over/under pattern. The short space between interlaces give the plain weave a high level of stability.

Material

Material(s) Carbon
Fibre(s) FT300B
Number of Filaments 3K

Construction

Total weight 220+3% gsm
Fibre orientation 0° / 90° (BT)
Warp 5.5 ends/cm
Weft 5.5 ends/cm

BENEFITS

• Outstanding visual quality for cosmetic parts
• Ideal for prepreg and infusion processes
• Excellent fibre alignment and flat weft yarn insertion
